Distributed CPU 1510SP-1 PN 100KB PROG 750KB DATA 6ES7510-1DJ01-0AB0 for Your Country
Product Details:
| Place of Origin: | Germany |
| Brand Name: | OTHER |
| Certification: | CE REACH RoHS |
| Model Number: | 6ES75101DJ010AB0 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 unit |
|---|---|
| Price: | $978.00/cartons |
|
Detail Information |
|||
| Warranty: | 12 Months, 12 Months | Type: | AC Drive |
|---|---|---|---|
| Customized: | NO | Control Mode: | Relay |
| Rated Power: | 24W | Nominal Voltage: | 220 |
| Power Phase Number: | 3 | Condition: | 100%new |
| Package: | Carton | ||
Product Description
Product Description
Specification
Product Type Symbol | CPU 1510SP-1 PN |
Hardware Function status | FS05 |
Firmware version | V2.9 |
Product function ● I&M data ● Replace the module during operation (hot swap) ● Clock synchronization mode | Yes; I&M0 to I&M3 Yes; Multiple hot swaps Yes; For PROFINET only; With minimum tissue block, 6 625 µs cycles |
Packaged ● STEP 7 TIA port, configurable/integrated, since version | V17 (firmware V2.9)/V13 SP1 upgrade version 4 (firmware V1.8) and above |
Configuration control By data group | Yes |
Operating element Running mode switch | |
Supply voltage Rating (DC) Allowable range, lower limit (DC) Allowable range, upper limit (DC) Reverse polarity protection | 24 V 19.2V 28.8V Yes |
The power supply and voltage break span ● Blackout/blackout crossover time | |
Input current Current consumption (rated) Current consumption, Max. Closing current, Max. I²t | 0.6A 0.9A 4.7A; Rated value 0.14 A²·s |
PPower The feed power on the backplane bus | 8.75 W |
Power loss Power loss, typical | 5.6W |
Memorizer Number of SIMATIC card slots Requires SIMATIC memory card | 1 Yes |
Working memory ● Integration (for programs) ● Integration (for data) | 750 kbyte |
Load memory ● Pluggable (SIMATIC memory card), maximum | 32 Gbyte |
